WITTENSTEIN alpha GmbH presents cymex® 5, the multifunctional software that enables bespoke drive trains to be designed more reliably, economically and energy efficiently.
We are constantly working to further improve cymex® 5.Following changes are included in the latest version.
Increase in the maximum permissible input speed (n1Max) for gear unit types SP+, TP+, DP+, and XP+
Additional consideration of motor power for improved drive unit design
New part numbers and updates to existing technical data
Addition of Turkish to the list of supported languages
New motor series:
Siemens: 1FL2
Mitsubishi: HK-JT, HK-MT, HK-KN, HK-FN, HK-SN
Yaskawa: SGMXJ, SGMXA, SGMXP, SGMXG
Jenaer Antriebstechnik (JAT): with various new motors
Extension of FAST LANE: The WITTENSTEIN alpha gearbox series CP and NP are now available up to size 035
New material numbers and data update
New motor manufacturers:
Heidrive with HMD / HMP series
Oriental Motor with various motors
New motor series:
Kollmorgen: KEM (Essentials)
Mitsubishi Electric: HK-RT / HK-ST
Siemens: 1FL6
BugFix - CAD request in combination actuator with coupling
Ordering code update of Hypoid gearboxes
New material numbers and data update
Technical Update
Migration on new Installer technology (MSI)
Integration of BCH couplings
Designations of customized motors printed on technical drawings
Optimization of memory consumption when creating profiles
New Galaxie® gearbox series AG available
New material numbers and data update
New 2 meter racks available
cyber® kit line available in standard motor database
Couplings more flexible placeable
Couplings with deviating diameters (input vs. output) now usable
Bug Fix: Fixed calculation issue concerning ring gear centre distance
New material numbers
Integration of axenia with hybrid cables
Adjusted and corrected data sheets for actuators
Bug Fix: Re-added Missing service life of bearing for CP
Bug Fix: Only available options are displayed in the Finish window for actuators
New material numbers
